Extension springs are a lower cost option when compared to torsion springs. These attach at either end to your track hanging hardware and to a cable from your door. Most extension springs have a safety cable strung through them to help prevent injuries if they give way.

Being fully informed about the function and proper operation of your garage door springs can help you to navigate any DIY maintenance or repairs. We’ve outlined all of the basics of extension springs here. We at Garage.com are committed to ensuring your safety when attempting any home maintenance and to recommending the top garage door pros near you. Read here to learn more.

What Are Garage Door Extension Springs and How Do They Work?

Extension springs and garage door springs of any type work in tandem with your garage door opener to easily lift and safely lower your doors. Unlike torsion springs, extension springs are side-mounted to your track brackets and to a hanging wheel or spool that winds the garage door cable.

These springs come with weight ratings. You’ll have to get a “dead weight” for your garage door to determine the spring rating you require. Dead weights are calculated by weighing your garage door while in its tracks with no spring tension applied.

Signs Your Garage Door Extension Springs Need Attention

You can diagnose most spring issues through routine visual inspections. We recommend cleaning and lubricating your garage door once every four to six months. This should include conducting a few operation cycles along with looking over all of your hardware and moving parts like rollers hinges.

A few signs that your garage door springs are weak or failing include:

  • Uneven door: If your door is raising or lowering unevenly, it usually means one or both of your springs need replacement. Noise often accompanies this, as your door rollers will scrape against the tracks while in use.
  • Labored operation: Springs assist the garage door opener to make raising and lowering less stressful on your system as a whole. If your opener is handling the entire weight of your door, it can lead to more costly repairs.
  • Visible rust buildup: Rust can be a sign of a weakened or compromised spring. Routinely lubricating your spring with a silicone or white lithium product and cleaning it of debris will allow you to maximize its lifespan.
  • Noisy operation: Noise is a harbinger of many other issues. This can include loose or damaged hardware, rusty springs, a compromised opener and more. Conduct full inspections of your door if you notice increased noise.

Remember that extension springs usually last between 8,000 and 10,000 cycles. This is usually seven to 10 years. Once you begin to approach this, it’s worth contacting one of our top licensed pros to handle any replacement tasks.

Extension Springs vs. Torsion Springs: Understanding the Differences

Often, extension springs are a cheaper option than torsion components. This is the primary reason why some homeowners opt for these in their garages, as torsion springs offer quieter operation, longer lifespans and higher lift capacities. In addition to this, these springs are compatible with a greater range of opener types, including jackshaft openers: a much quieter alternative to conventional systems.

Both springs provide tension to offset your garage door’s weight. Torsion springs operate through winding around a central bar. The more tightly-wound a spring is, the greater the force it can exert on your door. Extension springs are far simpler by comparison, and help to lift your door via pulling force.

DIY Maintenance Tips for Garage Door Extension Springs

Visual inspections  are a homeowner’s responsibility when maintaining any garage door opener system. This includes the opener itself, hardware and moving parts and the door panels.

Inspect and clean your door and opening system every four to six months while investigating any abnormal sounds that may come from your doors while in operation. Extension springs don’t require lubricant to operate properly, but we still recommend doing so to repel rust and dirt. A light layer of silicone or white lithium solution should suffice; you should always keep a cleaning rag on hand to wipe away any excess liquid.

Note that any breaks or gaps in your springs always require professional attention.

Choosing the Right Extension Springs for Your Garage Door

If you’ve determined that you need to replace the springs on your door, you should be aware of requirements to look for in a new spring. First, you’ll have to note whether the ends of your springs have visual color coding. These are indicative of its maximum lift capacity. Note that torsion springs also have color codes, which correspond to their wire diameter rather than actual lift capacity.

ColorPounds
White10/110/210
Green20/120/220
Yellow30/130/230
Blue40/140/240
Red50/150/250
Brown60/160/260
Orange70/170/270
Gold80/180/280
Light Blue90/190/290
Tan100/200/300

If your springs don’t have a discernible color on their ends, you’ll have to get a dead weight for your garage door to determine your required spring tension requirements. You have to fully release spring tension from your doors to accurately measure this, so we recommend getting professional assistance.

Common Questions About Garage Door Extension Springs

Extension springs come with three main types of ends: single-loop, double-loop and clipped ends. These usually appear on springs with differing lift capacities. Single loops are a serviceable option for lighter metal doors, while clipped ends are the most durable choice for heavier doors.

Loud banging noises from your garage door during operation are usually the first sign of spring damage. After you hear these sounds, you’ll often be able to see a gap or break in your springs. Other signs include grinding noises from your tracks and rollers, straining from your opener and visible sagging on one side of your garage door.

We always recommend replacing both springs if one breaks. Prolonged operation with one broken spring can weaken the functional one, making a double replacement necessary.
